Click on the part number for more information

ITEM IMAGE PART NO OEM Number(s) DESCRIPTION
ITEM IMAGE PART NO OEM Number(s) DESCRIPTION
- BH-7500-50 BH-7500-50 — Cable Sheave - Steel
- BH-7508-16A BH-7508-16A — Arm Restraint Main Gear - Adjustable
- BH-7542-62 BH-7542-62 — Overhead and Limit Bar Assembly - Blue
- BH-7542-62 BH-7542-62 — Overhead and Limit Bar Assembly - Blue
1- BH-7510-16 BH-7510-16 41410 Retaining Ring for 3/8" Shaft
3- BH-7500-62A BH-7500-62A 41411 Retaining Ring for 3/4" Shaft
4- BH-7500-49B BH-7500-49B 41388 Bushing - Machine (1-1/2" Outer Diameter x 3/4" Inner Diameter x .045" Thick)
7- BH-7529-18 BH-7529-18 FJ7206 Hose Clip – (Overhead)
10- BH-7500-50N BH-7500-50N FJ7116-1 Sheave
13- BH-7500-68 BH-7500-68 FJ7444-8 Shaft - Sheave
15- BH-7512-20 BH-7512-20 FJ839 Hose - Overhead
16- BH-7500-41 BH-7500-41 N33 Cable - Equalizer Assembly
19- BH-7503-29 BH-7503-29 FJ7871 Spacer (3/4")
21- BH-7508-34 BH-7508-34 FJ7613-2 Switch Bar - Assembly
22- BH-7521-45 BH-7521-45 41200 Cotter Pin (1/8" x 1" Long)
25- BH-7004-19 BH-7004-19 P461-2 Limit Switch - Single Phase Only
31- BH-7528-91 BH-7528-91 N410 Column Extension
34- BH-7508-53 BH-7508-53 FJ7664 Cylinder - Hydraulic
37- BH-7508-20 BH-7508-20 FJ7985-1 Handle - Actuator Pin
38- BH-7508-18 BH-7508-18 FJ7646-1 Pin - Actuator
42- BH-7535-58 BH-7535-58 FJ7656-2 Spring - Arm Restraint
43- BH-7508-17 BH-7508-17 FJ7749 Gear Block (120 Tooth)
44- BH-7519-28 BH-7519-28 14427 Spring Pin - Stainless (1/4" Diameter x 1-1/2" Long)
45- BH-7508-21 BH-7508-21 FJ7888 Kit - Arm Restraint (1 Arm) **NOTE: Includes items 34, 35, 36, 37, 38, 39, 40, 41, 42 & 73
47- BH-7502-33 BH-7502-33 N119-1 Cover - Sheave
49- BH-7502-90 BH-7502-90 FJ7444-14 Bracket - Latch Sheave Right
52- BH-7501-26 BH-7501-26 FJ7322 Sheave - Locking Latch
53- BH-7534-77 BH-7534-77 FJ7499 Hose Clip (Column)
57- BH-7512-41 BH-7512-41 FJ837 Hose - Power Unit
58- BH-7535-69 BH-7535-69 FJ7668 Tee - Branch
60- BH-7505-14 BH-7505-14 FJ7838 Pin - Arm
62- BH-7510-03 BH-7510-03 FJ7360 Slider Block
- Call For Details — Locking Latch Cable
- BH-7557-1124
(Call For Details) 		FJ-7595-1KIT Locking Latch Cable and Clamp Kit
1- Call For Details — Weldment - Overhead Left
2- Call For Details — Locknut - Flanged (3/8" -16NC)
3- Call For Details — Hex Head Cap Screw (3/8" -16NC x 3/4" Long)
4- Call For Details — Washer - Flat (3/8")
5- Call For Details — Weldment - Overhead Right
6- Call For Details — Screw - Slotted Hex Head Threaded (10 -24NC x 3/8" Long, For Overhead)
6- Call For Details — Screw - Slotted Pan Head Machine (5/16" -18NC x 3/8" Long, For Columns)
8- Call For Details — Hex Head Cap Screw - Flanged (3/8" -16NC x 1" Long)
9- Call For Details — Lockwasher - External Tooth (3/8")
14- Call For Details — Locking Latch Cable Assembly
16- Call For Details — Hex Nut - Zinc (1/4" -20NC)
17- Call For Details — Hex Lock Nut (1/2" -13NC)
18- Call For Details — Lock Nut - Insert (1/4" -20NC)
20- Call For Details — Hex Head Cap Screw (1/4" -20NC x 2" Long)
23- Call For Details — Bracket
24- Call For Details — Limit Switch - Assembly **NOTE: Includes items 62, 79 & 80
24- Call For Details — Limit Switch - Assembly Three Phase (For Units Using Above 250 Volts) **NOTE: Includes items 62, 79 & 80
25- BH-7537-21A
(Call For Details) 		FJ7979-1 Limit Switch - Three Phase Only
26- Call For Details — Cover - Limit Switch Bracket
28- Call For Details — Lockwasher - External Tooth (1/4")
29- Call For Details — Hex Head Cap Screw (1/4" -20NC x 3/4" Long)
30- Call For Details — Bracket - Latch Sheave Left
32- Call For Details — Hex Head Cap Screw - Flanged (3/8" -16NC x 3/8" Long)
35- Call For Details — L.H. Column Weldment
36- Call For Details — Bumper - Carriage (2 Required)
39- Call For Details — Bumper - Approach (Door, 18" Long, 2 Required)
40- BH-7537-52
(Call For Details) 		N84 Carriage Yoke - Weldment Left
41- Call For Details — Ring - Retaining
47- Call For Details — Pan Head Machine Screw - Plated (1/4" -20 x 3/8" Long, 1 Required)
48- Call For Details — Locknut - Flanged (1/4" -20NC)
50- Call For Details — Hex Head Cap Screw (1/4" -20NC x 3/4" Long)
54- Call For Details — R.H. Column Weldment
55- Call For Details — Hex Head Cap Screw - External Tooth Lockwashers and Hex Nuts (5/16" -18NC x 3/4" Long)
59- BH-7537-53
(Call For Details) 		N85 Carriage Yoke - Weldment Right
61- Call For Details — Cotter Pin (3/16" x 2" Long)
63- Call For Details — Anchor - Zinc Plated Steel Wedge 3/4" x 5-1/2" - Box of 20
64- Call For Details — Kit - Wheel Spotting Dish
