ITEM IMAGE PART NO OEM Number(s) DESCRIPTION
ITEM IMAGE PART NO OEM Number(s) DESCRIPTION
9- BH-7485-0299 BH-7485-0299 TP12KC-D-042 Limit Switch
22- BH-7485-0554 BH-7485-0554 TP12KC-D-026 Hydraulic Cylinder
23- BH-7485-0555 BH-7485-0555 TP12KC-D-026x Seal Kit for Hydraulic Cylinder
25- BH-7485-0582 BH-7485-0582 TP12KC-D-047 Hydraulic Hose, 71"
28- BH-7485-0306 BH-7485-0306 TP12KC-D-046 Tee Fitting
29- BH-7485-0585 BH-7485-0585 TP12KC-D-073 Equalizer Cable, 38' 1-1/2"
32- BH-7485-0321 BH-7485-0321 TP12KC-D-064 Arm Restraint Main Gear
36- BH-7485-0322 BH-7485-0322 TP12KC-D-066 Arm Restraint Engage Gear
37- BH-7485-0319 BH-7485-0319 TP12KC-D-065 Cotter Pin
41- BH-7485-0592 BH-7485-0592 TP12KC-D-060 Lift Pad Adapter Base
42- BH-7101-00 BH-7101-00 TP12KC-D-059 Rubber Pad
44- BH-7485-0595 BH-7485-0595 TP12KC-D-063 Swing Arm Pin
64- BH-7512-92 BH-7512-92 TP12KC-D-002 Shim Assortment 150 pieces (3 Sizes)
68- BH-7070-K BH-7070-K SVI Exclusive Power Station (for 2-Post Lift)
69- BH-9702 BH-9702 — Dual Wheel Spotter Dish 20-1/8” x 15” Wide
1- Call For Details — Power Unit
2- BH-7485-0568
(Call For Details) 		TP12KC-D-053 Mainside Column
3- BH-7485-0569
(Call For Details) 		TP12KC-D-001 Offside Column
4- BH-7485-0570
(Call For Details) 		TP12KC-D-036 Column Extension
5- BH-7485-0293
(Call For Details) 		TP12KC-D-021 Overhead Shut-Off Bar
6- BH-7485-0292
(Call For Details) 		TP12KC-D-023 Cushion, Shutoff Bar
7- BH-7485-0352
(Call For Details) 		TP12KC-D-019 Bolt, M8 x 40mm
8- BH-7485-0571
(Call For Details) 		TP12KC-D-020 Washer, D8
10- BH-7485-0572
(Call For Details) 		TP12KC-D-043 Limit Switch Wiring
11- BH-7485-0384
(Call For Details) 		TP12KC-D-040 Cover Plate, Limit Switch
12- BH-7485-0573
(Call For Details) 		TP12KC-D-041 Housing, Limit Switch
13- BH-7485-0350
(Call For Details) 		TP12KC-D-039 Screw
14- BH-7485-0574
(Call For Details) 		TP12KC-D-034 Cable Pulley
15- BH-7485-0575
(Call For Details) 		TP12KC-D-035 Pulley Shaft
16- BH-7485-0553
(Call For Details) 		TP12KC-D-049 Latch Cover
17- BH-7485-0576
(Call For Details) 		TP12KC-D-033 Spacer #2
18- BH-7485-0577
(Call For Details) 		TP12KC-D-032 Spacer #1
19- BH-7485-0578
(Call For Details) 		TP12KC-DX-025 Carriage
20- BH-7485-0579
(Call For Details) 		TP12KC-D-024 Sliding Rub Block
21- BH-7485-0580
(Call For Details) 		TP12KC-D-078 Washer
24- BH-7485-0581
(Call For Details) 		TP12KC-D-070 Cylinder Fitting
26- BH-7485-0583
(Call For Details) 		TP12KC-D-045 Hydraulic Hose, 33' 1"
27- BH-7485-0584
(Call For Details) 		TP12KC-D-044 Hydraulic Hose, 8-1/4"
30- Call For Details — Washer
31- BH-7485-0366
(Call For Details) 		TP12KC-D-071 Nut
33- BH-7485-0586
(Call For Details) 		TP12KC-D-027 Bolt
34- BH-7485-0587
(Call For Details) 		TP12KC-D-028 Flat Washer
35- BH-7485-0588
(Call For Details) 		TP12KC-D-029 Nut
38- BH-7485-0589
(Call For Details) 		TP12KC-DX-003 Arm Restraint Plunger
39- BH-7485-0590
(Call For Details) 		TP12KC-D-068 Arm Restraint Spring
40- BH-7485-0591
(Call For Details) 		TP12KC-D-069 Pull Ring
43- BH-7485-0594
(Call For Details) 		TP12KC-D-058 Elevator Bolt, M10 x 16mm
45- BH-7485-0596
(Call For Details) 		TP12KC-D-062 Swing Arm
46- BH-7485-0597
(Call For Details) 		TP12KC-D-061 Arm Slider
47- BH-7485-0598
(Call For Details) 		TP12KC-D-004 Nesting Height Extension 2.5"
48- BH-7485-0599
(Call For Details) 		TP12KC-D-005 Nesting Height Extension 5"
49- BH-7485-0600
(Call For Details) 		TP12KC-D-057 Tee Fitting
50- BH-7485-0601
(Call For Details) 		TP12KC-D-055 Air Line Tubing, D6 x 8"
51- BH-7485-0602
(Call For Details) 		TP12KC-D-054 Air Line Tubing, D6 x 354"
52- BH-7485-0603
(Call For Details) 		TP12KC-D-056 Air Line Tubing, D6 x 2"
53- BH-7485-0604
(Call For Details) 		TP12KC-D-051 Palm Button Valve
54- BH-7485-0605
(Call For Details) 		TP12KC-D-050 Elbow Fitting
55- BH-7485-0367
(Call For Details) 		TP12KC-D-074 O-Ring
56- BH-7485-0606
(Call For Details) 		TP12KC-D-075 Tee Fitting
57- BH-7485-0607
(Call For Details) 		TP12KC-D-076 Quick Fitting
58- BH-7485-0608
(Call For Details) 		TP12KC-D-077 Close Nut
59- BH-7485-0545
(Call For Details) 		TP12KC-D-006 Retaining Ring
60- BH-7485-0609
(Call For Details) 		TP12KC-D-018 Overhead Crossbeam
61- BH-7485-0610
(Call For Details) 		TP12KC-D-030 Connecting Plate
62- BH-7485-0611
(Call For Details) 		TP12KC-D-031 Cable Nut, M16
63- BH-7485-0334
(Call For Details) 		TP12KC-D-022 Lock Nut, M8
65- Call For Details — Anchor Bolt, 3/4" x 7"
66- BH-7485-0613
(Call For Details) 		TP12KC-D-038 Screw
67- BH-7485-0612
(Call For Details) 		TP12KC-D-037 Hose Clip
69- BH-9701
(Call For Details) 		— Single Wheel Spotter Dish 10-3/4” x 15” Wide
