ITEM IMAGE PART NO OEM Number(s) DESCRIPTION
ITEM IMAGE PART NO OEM Number(s) DESCRIPTION
4- BH-7485-0285 BH-7485-0285 165948T\*01-028 Cable Sheave/Pulley
5- BH-7485-0284 BH-7485-0284 165948T\*01-026 Sheave / Pulley Pin
7- BH-7485-0339 BH-7485-0339 165948T\*01-084 Swivel Pad
8- BH-7485-0340 BH-7485-0340 165948T\*01-083 Rubber Pad
12- BH-7485-0344 BH-7485-0344 165948T\*01-003 Nesting Height Extension 2”
13- BH-7485-0345 BH-7485-0345 165948T\*01-004 Nesting Height Extension 4”
15- BH-7485-0347 BH-7485-0347 165948T\*01-077 Hydraulic Cylinder
19- BH-7485-0280 BH-7485-0280 165948T\*01-065 Elbow Fitting
24- BH-7485-0298 BH-7485-0298 165948T\*01-070 Housing, Limit Switch
25- BH-7485-0349 BH-7485-0349 165948T\*01-071 Limit Switch
31- BH-7485-0306 BH-7485-0306 165948T\*01-046 Hydraulic Tee Fitting
32- BH-7485-0304 BH-7485-0304 165948T\*01-048 Hydraulic Hose, 54.3”
33- BH-7485-0305 BH-7485-0305 165948T\*01-045 Hydraulic Hose, 71”
34- BH-7485-0303 BH-7485-0303 165948T\*01-047 Hydraulic Hose, 207”
36- BH-7485-0353 BH-7485-0353 165948T\*01-081 Arm Restraint Main Gear
37- BH-7485-0320 BH-7485-0320 165948T\*01-080 Hex Head Capscrew
38- BH-7485-0532 BH-7485-0532 165948T\*01-094 Swing Arm Pin
45- BH-7485-0361 BH-7485-0361 165948T\*01-0104 Limit Block
51- BH-7485-0279 BH-7485-0279 165948T\*01-096 Sleeve
63- BH-7485-0308 BH-7485-0308 165948T\*01-050 Slider Block
67- BH-7485-0369 BH-7485-0369 165948T\*01-103 Screw
70- BH-7485-0372 BH-7485-0372 165948T\*01-036 Large Bracket
71- BH-7485-0373 BH-7485-0373 165948T\*01-006 Lock Release Cable Pulley
72- BH-7485-0374 BH-7485-0374 165948T\*01-007 Pin
73- BH-7485-0375 BH-7485-0375 165948T\*01-008 Cotter Pin
78- BH-7485-0380 BH-7485-0380 165948T\*01-009 Lock Release Cover (Off Side)
79- BH-7485-0381 BH-7485-0381 165948T\*01-040 Lock Release Cover (Main Side)
83- BH-7070-K BH-7070-K SVI Exclusive Power Station (for 2-Post Lift)
84- BH-9702 BH-9702 — Dual Wheel Spotter Dish 20-1/8" x 15" Wide
1- Call For Details — Power Unit
2- BH-7485-0535
(Call For Details) 		165948T\*01-038 Main Side Column
3- BH-7485-0534
(Call For Details) 		165948T\*01-001 Offside Column
6- BH-7485-0338
(Call For Details) 		165948T\*01-024 Flat Washer
9- Call For Details — Socket Head Cap Screw
10- BH-7485-0342
(Call For Details) 		165948T\*01-087 Nut
11- BH-7485-0343
(Call For Details) 		165948T\*01-072 Hex Head Capscrew
14- BH-7485-0346
(Call For Details) 		165948T\*01-067 Height Adapter Hanger Bracket
16- Call For Details — Seal Kit for Hyd. Cylinder
17- BH-7485-0264
(Call For Details) 		165948T\*01-075 Jam Nut, Cylinder
18- BH-7485-0265
(Call For Details) 		165948T\*01-076 Hex Nut, Cylinder
20- BH-7485-0296
(Call For Details) 		165948T\*01-034 Tee Fitting
21- BH-7485-0291
(Call For Details) 		165948T\*01-097 Return Line #1
22- BH-7485-0301
(Call For Details) 		165948T\*01-037 Return Line #2
23- BH-7485-0293
(Call For Details) 		165948T\*01-033 Overhead Shut-Off Bar
26- BH-7485-0350
(Call For Details) 		165948T\*01-005 Screw
27- BH-7485-0290
(Call For Details) 		165948T\*01-063 Flat Washer
28- BH-7485-0342
(Call For Details) 		165948T\*01-087 Nut
29- BH-7485-0331
(Call For Details) 		165948T\*01-057 Elbow Fitting
35- BH-7485-0352
(Call For Details) 		165948T\*01-101 Hex Head Capscrew
39- BH-7485-0355
(Call For Details) 		165948T\*01-082 Outside Front Arm Left (LH)
40- BH-7485-0356
(Call For Details) 		165948T\*01-092 Outside Front Arm Right (RH)
41- BH-7485-0357
(Call For Details) 		165948T\*01-093 Middle Front Arm
42- BH-7485-0358
(Call For Details) 		165948T\*01-091 Inner Front Arm
43- BH-7485-0359
(Call For Details) 		165948T\*01-074 Outside Rear Arm
44- BH-7485-0360
(Call For Details) 		165948T\*01-086 Inner Rear Arm
46- BH-7485-0362
(Call For Details) 		165948T\*01-035 Cylinder Mount Bracket
47- BH-7485-0287
(Call For Details) 		165948T\*01-030 Overhead Crossbeam
48- BH-7485-0288
(Call For Details) 		165948T\*01-031 Hex Head Capscrew
49- BH-7485-0282
(Call For Details) 		165948T\*01-023 Flat Washer
50- BH-7485-0363
(Call For Details) 		165948T\*01-029 Pin
52- BH-7485-0354
(Call For Details) 		165948T\*01-064 Fitting Adapter
53- BH-7485-0365
(Call For Details) 		165948T\*01-095 Retaining Ring
54- BH-7485-0292
(Call For Details) 		165948T\*01-098 Cushion for Shutoff Bar
55- BH-7485-0281
(Call For Details) 		165948T\*01-022 Nut
56- Call For Details — Equalizer Cable Assembly 33' 8"
57- Call For Details — Washer, D16
58- BH-7485-0366
(Call For Details) 		165948T\*01-090 Nut
59- BH-7485-0302
(Call For Details) 		165948T\*01-039 Rubber Grommet
60- BH-7485-0367
(Call For Details) 		165948T\*01-058 O-Ring
61- BH-7485-0334
(Call For Details) 		165948T\*01-032 Nylon Lock Nut
62- BH-7485-0368
(Call For Details) 		165948T\*01-059 Hex Head Capscrew
65- Call For Details — Shim
66- BH-7075-03
(Call For Details) 		165948T\*01-056 Wedge Anchor Bolt
68- BH-7485-0370
(Call For Details) 		165948T\*01-027 Cotter Pin
69- BH-7485-0371
(Call For Details) 		165948T\*01-025 Bearing
74- BH-7485-0376
(Call For Details) 		165948T\*01-106 Cable Lock
75- BH-7485-0377
(Call For Details) 		165948T\*01-107 Turnbuckle
76- BH-7485-0378
(Call For Details) 		165948T\*01-108 Hose Cover (some models)
77- BH-7485-0379
(Call For Details) 		165948T\*01-010 Flat Washer
80- BH-7485-0533
(Call For Details) 		165948T\*01-049 Carriage
81- BH-7485-0384
(Call For Details) 		165948T\*01-068 Cover Plate, Limit Switch
82- BH-7485-0385
(Call For Details) 		165948T\*01-069 Cable Nut
84- BH-9701
(Call For Details) 		— Single Wheel Spotter Dish 10-3/4" x 15" Wide
