Click on the part number for more information

ITEM IMAGE PART NO OEM Number(s) DESCRIPTION
ITEM IMAGE PART NO OEM Number(s) DESCRIPTION
9- BH-7485-0322 BH-7485-0322 MSC-6KLP-085 Arm Restraint Engage Gear
10- BH-7485-0321 BH-7485-0321 MSC-6KLP-082 Arm Restraint Main Gear
13- BH-7485-0319 BH-7485-0319 MSC-6KLP-086 Cotter Pin, D6x38
19- BH-7488S-0285 BH-7488S-0285 MSC-6KLP-104 Gear Block
20- BH-7488S-0286 BH-7488S-0286 MSC-6KLP-105 Spring
22- BH-7488S-0288 BH-7488S-0288 MSC-6KLP-108 Screw, M8x20
23- BH-7488S-0289 BH-7488S-0289 MSC-6KLP-109 Plate, Fixing Pin
34- BH-7485-0344 BH-7485-0344 MSC-6KLP-114 Nesting Height Extension 2"
35- BH-7485-0345 BH-7485-0345 MSC-6KLP-113 Nesting Height Extension 4"
39- BH-7488S-0301 BH-7488S-0301 MSC-6KLP-056 Top, Sliding Block
40- BH-7488S-0302 BH-7488S-0302 MSC-6KLP-057 Side, Sliding Block
54- BH-7488S-0314 BH-7488S-0314 MSC-6KLP-040Ax Seal Kit for Hydraulic Cylinder
68- BH-7488S-0327 BH-7488S-0327 MSC-6KLP-047 Seal Ring, D16
115- BH-7070-K BH-7070-K SVI Exclusive Power Station (for 2-Post Lift)
1- BH-7007-03
(Call For Details) 		PU-110V-L-K Power Unit
2- BH-7485-0290
(Call For Details) 		MSC-6KLP-069 Flat Washer, D8
3- BH-7488S-0275
(Call For Details) 		MSC-6KLP-068 Bolt, M8x25
4- BH-7488S-0276
(Call For Details) 		MSC-6KLP-070 Nut, M8
5- BH-7485-0591
(Call For Details) 		MSC-6KLP-092 Pull Knob
6- BH-7485-0401
(Call For Details) 		MSC-6KLP-091 Retaining Ring, D18
7- BH-7488S-0277
(Call For Details) 		MSC-6KLP-088 Spring, Gear Pin
8- BH-7488S-0278
(Call For Details) 		MSC-6KLP-087 Gear Pin, Small
11- BH-7485-0315
(Call For Details) 		MSC-6KLP-096 Flat Washer, D10
12- BH-7488S-0279
(Call For Details) 		MSC-6KLP-097 Bolt, M10x35
14- BH-7488S-0280
(Call For Details) 		MSC-6KLP-116 LH, Release Handle
15- BH-7488S-0281
(Call For Details) 		MSC-6KLP-118 RH, Release Handle
16- BH-7488S-0282
(Call For Details) 		MSC-6KLP-117 Handle Ball
17- BH-7488S-0283
(Call For Details) 		MSC-6KLP-107 Fixing Pin
18- BH-7488S-0284
(Call For Details) 		MSC-6KLP-106 Cap Bolt
21- BH-7488S-0287
(Call For Details) 		MSC-6KLP-103 Screw, M6x12
24- BH-7488S-0290
(Call For Details) 		MSC-6KLP-102 OS, Swing Arm Pin
25- BH-7488S-0291
(Call For Details) 		MSC-6KLP-090 MS, Swing Arm Pin
26- BH-7485-0351
(Call For Details) 		MSC-6KLP-089 Retaining Ring, D38
27- BH-7488S-0292
(Call For Details) 		MSC-6KLP-119 Slotted Cover Plate
28- BH-7485-0350
(Call For Details) 		MSC-6KLP-021 Screw, M6x12
29- BH-7488S-0293
(Call For Details) 		MSC-6KLP-073x Swivel Pad Adapter with Rubber Pad
30- BH-7488S-0294
(Call For Details) 		MSC-6KLP-073 Swivel Pad Base Only
31- BH-7488S-0295
(Call For Details) 		MSC-6KLP-074 Threaded Adaptor-Long
32- BH-7488S-0296
(Call For Details) 		MSC-6KLP-076 Threaded Adaptor-Short
33- BH-7488S-0297
(Call For Details) 		MSC-6KLP-072 Rubber Pad
36- BH-7488S-0298
(Call For Details) 		MSC-6KLP-081 Handle, Swing Arm
37- BH-7488S-0299
(Call For Details) 		MSC-6KLP-079 Screw, M8x12
38- BH-7488S-0300
(Call For Details) 		MSC-6KLP-080 Spring Washer D10
41- BH-7488S-0303
(Call For Details) 		MSC-6KLP-058 Sliding Block Frame
42- BH-7488S-0304
(Call For Details) 		MSC-6KLP-071 Screw, M4x10
43- BH-7488S-0305
(Call For Details) 		MSC-6KLP-110 Bracket, Release Cable
44- BH-7488S-0306
(Call For Details) 		MSC-6KLP-036 Chain (See SVI Chain Book)
45- BH-7488S-0307
(Call For Details) 		MSC-6KLP-054 Upper Chain Block
46- BH-7488S-0308
(Call For Details) 		MSC-6KLP-052 Chain Pin
47- BH-7488S-0309
(Call For Details) 		MSC-6KLP-053 Split Pin, D3x20
48- BH-7488S-0043
(Call For Details) 		MSC-6KLP-050 Nut, M20
49- BH-7488S-0310
(Call For Details) 		MSC-6KLP-049 Lock Nut, M20
50- BH-7488S-0311
(Call For Details) 		MSC-6KLP-066 Lower Chain Block
51- BH-7488S-0312
(Call For Details) 		MSC-6KLP-067 Bolt, M16x60
52- Call For Details — Lock Nut, M16
53- BH-7488S-0313
(Call For Details) 		MSC-6KLP-040A Hydraulic Cylinder
55- BH-7488S-0315
(Call For Details) 		MSC-6KLP-038 Roller Seat
56- BH-7488S-0316
(Call For Details) 		MSC-6KLP-039 Nut, M27
57- BH-7488S-0317
(Call For Details) 		MSC-6KLP-037 Roller Bearing
58- BH-7488S-0318
(Call For Details) 		MSC-6KLP-032 Spindle
59- BH-7488S-0319
(Call For Details) 		MSC-6KLP-034 Bearing, D30x2
60- BH-7488S-0320
(Call For Details) 		MSC-6KLP-035 Nut, M24
61- BH-7488S-0321
(Call For Details) 		MSC-6KLP-033 Roller Bearing Cover
62- BH-7485-0331
(Call For Details) 		MSC-6KLP-041 90 degree Elbow Fitting
63- BH-7488S-0322
(Call For Details) 		MSC-6KLP-042 Hydraulic Hose
64- BH-7488S-0323
(Call For Details) 		MSC-6KLP-045 O-Ring, D10xD2
65- BH-7488S-0324
(Call For Details) 		MSC-6KLP-043 Straight Fitting
66- BH-7488S-0325
(Call For Details) 		MSC-6KLP-044 Throttle Washer
67- BH-7488S-0326
(Call For Details) 		MSC-6KLP-046 Retaining Ring, D10
69- BH-7488S-0328
(Call For Details) 		MSC-6KLP-048 Cylinder Key Tab
70- BH-7488S-0329
(Call For Details) 		MSC-6KLP-051 Bolt, M8x30
71- BH-7488S-0330
(Call For Details) 		MSC-6KLP-060 Safety Latch
72- BH-7485-0317
(Call For Details) 		MSC-6KLP-059 Lock Latch Spring
73- BH-7488S-0331
(Call For Details) 		MSC-6KLP-063 Latch Cam
74- BH-7488S-0332
(Call For Details) 		MSC-6KLP-062 Lock Nut, M10
75- BH-7488S-0333
(Call For Details) 		MSC-6KLP-061 Steel Rod
76- BH-7485-0311
(Call For Details) 		MSC-6KLP-065 Lock Nut M30
77- BH-7488S-0334
(Call For Details) 		MSC-6KLP-055 Carriage
78- BH-7488S-0335
(Call For Details) 		MSC-6KLP-093 Lifting Frame
79- BH-7488S-0336
(Call For Details) 		MSC-6KLP-094 Bolt, M16x25
80- BH-7488S-0337
(Call For Details) 		MSC-6KLP-095 Bolt, M16x40
81- BH-7488S-0338
(Call For Details) 		MSC-6KLP-025 Spring Washer, D16
82- BH-7488S-0056
(Call For Details) 		MSC-6KLP-024 Flat Washer, D16
83- BH-7488S-0339
(Call For Details) 		MSC-6KLP-011 Ramp
84- BH-7488S-0340
(Call For Details) 		MSC-6KLP-007 Hook
85- BH-7485-0274
(Call For Details) 		MSC-6KLP-008 Flat Washer, D6
86- BH-7488S-0341
(Call For Details) 		MSC-6KLP-009 Spring Washer, D6
87- BH-7488S-0342
(Call For Details) 		MSC-6KLP-010 Bolt, M6x25
88- BH-7485-0545
(Call For Details) 		MSC-6KLP-002 Retaining Ring, D25
89- BH-7488S-0343
(Call For Details) 		MSC-6KLP-003 Roller
90- BH-7488S-0344
(Call For Details) 		MSC-6KLP-004 Bearing, D52xD25x15
91- BH-7488S-0345
(Call For Details) 		MSC-6KLP-006 Roller Bushing
92- BH-7488S-0346
(Call For Details) 		MSC-6KLP-005 Roller Pin
93- BH-7488S-0347
(Call For Details) 		MSC-6KLP-026 Bolt, M16x50
94- BH-7488S-0348
(Call For Details) 		MSC-6KLP-027 Column
95- BH-7488S-0349
(Call For Details) 		MSC-6KLP-029 Top Plate
96- BH-7488S-0350
(Call For Details) 		MSC-6KLP-001 Base
97- BH-7488S-0351
(Call For Details) 		MSC-6KLP-115 Bolt, M8x25
98- BH-7488S-0352
(Call For Details) 		MSC-6KLP-019 Support Frame
99- BH-7488S-0353
(Call For Details) 		MSC-6KLP-018 Spacer
100- BH-7488S-0354
(Call For Details) 		MSC-6KLP-017 Flat Washer
101- BH-7488S-0355
(Call For Details) 		MSC-6KLP-016 Bolt, M12x35
102- BH-7488S-0356
(Call For Details) 		MSC-6KLP-020 Bolt, M10x25
103- BH-7488S-0357
(Call For Details) 		MSC-6KLP-078 LH, Mainside Arm
104- BH-7488S-0358
(Call For Details) 		MSC-6KLP-077 LH, MS Arm Extension
105- BH-7488S-0359
(Call For Details) 		MSC-6KLP-098 RH, Mainside Arm
106- BH-7488S-0360
(Call For Details) 		MSC-6KLP-099 RH, MS Arm Extension
107- BH-7488S-0361
(Call For Details) 		MSC-6KLP-101 RH, Offside Arm
108- BH-7488S-0362
(Call For Details) 		MSC-6KLP-100 RH, OS Arm Extension
109- BH-7488S-0363
(Call For Details) 		MSC-6KLP-111 LH, Offside Arm
110- BH-7488S-0364
(Call For Details) 		MSC-6KLP-112 LH, OS Arm Extension
111- BH-7488S-0365
(Call For Details) 		MSC-6KLP-012 Pallet Jack Assembly
112- BH-7488S-0366
(Call For Details) 		MSC-6KLP-015 Ball
113- BH-7488S-0367
(Call For Details) 		MSC-6KLP-014 Cotter Pin
114- BH-7488S-0368
(Call For Details) 		MSC-6KLP-013 Pin
116- BH-9701
(Call For Details) 		— Single Wheel Spotter Dish 10-3/4" x 15" Wide
